3D LASER SCANNING

Why do you need 3D Scanning?

  • Manage complex projects

  • Install Faster

  • Accurate Surveys
    – Documenting the “as-is” condition
    – Retrofitting

  • 3D Scanning Has Become Affordable
    – Price for technology has decreased
    – Less field re-work on projects using scan data

  • Time Equals Money
    – Coordination and Pre-fabrication

Field Use Applications

  • Accurate Field Measurements

  • FF/FL

  • Floor Inspection

  • Prefabrication

  • Design -Detail -Fabricate and Install with confidence

  • As-Built Verification and Embed Placement

  • QA/QC

  • Foundation Corners, Steps & Pilasters, Rebar Clarence

  • Anchor Bolt Verification

  • Defining the location of rebar and post tension cables in newly poured concrete

  • Railings

  • Overall Design Concept

  • No As-Builts

MEP Below Grade & In Foundations

– Trench location QA/QC and slope
– Stub-up Locations
– Sleeve penetration locations in foundation
– Light pole location
– Solar Panel Fields

Making measurements directly to 3D surfaces

– Create 3D Solid
– Create Center Line
– Obtain Diameter and Vertical Distance to Ground

Rebar and Post Tension Cable Location

– Scan the location of rebar in the forms
– Drill into newly poured concrete
– Install/ reposition embedded fixtures

Contact us today to receive a FREE site visit up to 4 hours of scanning and a scan file
